Case Study
Fume Incinerator Custom Cooling Towers for a Carbon Fiber Manufacturer
Carbon Fiber Manufacturing Industrial Cooling Tower: Key Takeaways
- The challenge: Design a custom heat exchanger to cool hot air streams and integrate seamlessly into their space.
- The solution: A custom cooling tower that can withstand the high temperatures and rigorous demands of carbon fiber manufacturing.
- The numbers: Unit recovers 6,300 SCFM of 1,600ᵒ-1,750ᵒF hot air leaving an incinerator, cooling air to 350ᵒF for the baghouse.
Details
Industry
Carbon fiber manufacturing
Lead Time
8-10 weeks post-design approval
Product
Cooling tower heat exchanger
Location
Tennessee, USA
Materials
309 and 304L stainless steel and carbon steel
Applied Capabilities
Custom unit design, fabrication, on-site consultation
Heat and Air Specifications
Recover 6,300 SCFM of 1,600ᵒ to 1,750ᵒF hot air leaving a thermal fume incinerator, cooling it down to 350ᵒF before entering a bag-house filtration system for final cleaning.
High-Temperature Waste Heat Recovery for Carbon Fiber Manufacturing
PRE-heat Inc. stepped up to the challenge, delivering the PRE-heat Model V13/31-72-85.5-2S heat exchangers designed to exacting standards. Constructed from premium materials including stainless steel tubes and tube sheets, these exchangers were engineered to withstand the high temperatures and rigorous demands of the carbon fiber manufacturing process.
How To Save Energy in a Manufacturing Plant with a Heat Exchanger
We provided more efficiency while simultaneously showcasing our proprietary free-floating air seal expansion system. This system is the best in the industry and lasts longer than other units, while still maintaining the integrity of the unit and the seal between air streams. For this project, the shell was all dye penetrated tested, and was built while using our standard Quality Control Sheets/system.
Partner with the Leading Industrial Cooling Tower Manufacturer
Pre-heat engineers harness decades of experience to design, build, and install custom heat exchangers tailored to the needs of our clients in the building materials space. Recover heat, save energy, and lower bills with PRE-heat. Start your project today.
